Product Name: FCDS-02P Air Disinfector

Product use: suitable for air disinfection in general operating rooms, delivery rooms, blood wards, burn wards, protective isolation wards, and intensive care wards; disinfection supply center inspection packaging sterilization area and sterile item storage area, severe dialysis Air disinfection in the center; air disinfection in examination rooms, treatment rooms, infectious disease clinics and other places.

Technical parameter requirements:

1. Using ultraviolet lamp + active mist ion disinfection and sterilization, the sterilization is broad-spectrum and thorough; it contains activated carbon/HEPA high-efficiency filter and primary filter, which can effectively remove volatile gases in the air, various odors and filter hair, Large dust particles such as dust;

2. Appearance size 450×388×770 (mm3), movable floor equipment;

3. Coexistence of human and machine, continuous dynamic disinfection can be carried out in the state of people, without any harm to people and items;

4. The weight of the whole machine is less than or equal to 18kg, the rated circulating air volume is more than or equal to 950m³/h, and it can be applied to places with a volume of 80m³ and below;

5. Rated power 120W; power supply 220V 50Hz;

6. The radiation intensity of ultraviolet rays at 1 meter can reach 25μW/cm2; (provincial CDC or third-party testing agency testing reports can be provided)

7. Equipped with an active mist ion generating core, the hydroxyl radical release efficiency of the active mist ion generating core should not be less than 6.9×1011/s, and the life span of hydroxyl radicals in the released active mist ions should not be less than 8 minutes;

8. The safety of hydroxyl radicals generated by the active mist ion generator core has been verified by acute inhalation toxicity experiments;

9. The equipment continues to work for 1 hour, and the residual ozone content is less than 0.003mg/m³.

★10. The device is equipped with 4G/5G communication chip, which can be connected to the IoT device management platform. After logging in to the management platform, you can view the operating status of the device and the service life of consumables online, and you can remotely control the opening and closing of the device online;

★Disinfection effect requirements:

1) The killing rate of Staphylococcus albus was more than 99.90% when the equipment was opened for 1 hour in a space of 20m3;

2) Open the equipment for 1 hour in 80m3 space, and the natural bacteria extinction rate is ≥ 90%;

★3) When the active mist ion generating module runs for 15min, the killing rate of the original strain of COVID-19 virus should be greater than 99.90% (the test report of the authoritative certification and testing institution or the authoritative scientific research institution should be provided);

4) When the active mist ion generating module runs for 15min, the killing rate of delta virus strain shall be greater than 99.90% (the test report of the authoritative certification and testing institution or the authoritative scientific research institution shall be provided);

★5) When the active mist ion generating module runs for 15min, the killing rate of Omicron virus strain shall be greater than 99.90% (the test report of the authoritative certification and testing institution or the authoritative scientific research institution shall be provided);

6) When the active mist ion generating module operates for 120min, the killing rate of methicillin-resistant Staphylococcus aureus (MRSA) shall be greater than 95.00% (the test report of the authoritative certification and testing institution or the authoritative scientific research institution shall be provided);

7) Open the equipment for 2 hours in a space of 30m3, and the bacteria removal rate of Klebsiella pneumoniae shall be greater than 99.90% (the test report of an authoritative certification and testing institution or an authoritative scientific research institution shall be provided).
